Porcelain Disc Insulator

Introduction



As a manufacturer located in China, we are proud to introduce our flagship product – the Porcelain Disc Insulator. Our porcelain disc insulators are designed to provide reliable and durable solutions for electrical industries. These insulators are made of high-quality materials, which make them strong and long-lasting. Our Porcelain Disc Insulator is known for its excellent performance and ability to withstand extreme weather conditions, making it the perfect choice for merchants in countries outside of China.



Features



The Porcelain Disc Insulator is made of high-quality porcelain material which makes it an excellent choice for electric power transmission and distribution lines. It is designed to provide reliable performance, safety, and durability under extreme environments. Here are some of the features that make our porcelain disc insulator unique and attractive to merchants.



1. High Strength



Our porcelain disc insulator is made of top-quality porcelain material which makes it resistant to mechanical, thermal, and electrical stresses. It has a high compressive strength, bending strength, and impact strength, making it durable and long-lasting.



2. Excellent Performance



Our Porcelain Disc Insulator is designed to provide excellent performance in different weather conditions. It can withstand temperature changes from -40 degrees Celsius to +50 degrees Celsius, making it suitable for use in extreme weather conditions.



3. Corrosion Resistant



Our porcelain insulators are made of materials that are resistant to corrosion. They can withstand chemical reactions caused by environmental factors like dust, salt, moisture, and other pollutants which can cause corrosion in metal and other materials.



4. Waterproof



Our porcelain disc insulator is designed to be waterproof. It has a smooth surface that makes it easy to clean and prevents the accumulation of dirt and other contaminants. This feature ensures that the insulator remains clean and dry, which is crucial for its optimal performance.



5. Easy Installation



Our porcelain insulators are designed to be easy to install. They can be attached using different hardware, making it easy to install them on different structures.



Applications



Our Porcelain Disc Insulator is suitable for different applications in electrical industries. Some of the applications for our porcelain insulators include:



1. AC power transmission lines



Our porcelain disc insulator is suitable for AC power transmission. It can be used in different voltage lines and can withstand various electrical stresses.



2. Distribution lines



Our porcelain insulators can be used in distribution lines to support power lines, transformers, and other equipment.



3. Substation equipment



Our porcelain insulators can also be used in substation equipment, where they provide insulation for transformers, switchgear, and other equipment.



4. Railway electrification



Our porcelain insulators are also suitable for use in rail electrification systems. They can withstand mechanical stresses caused by wind, vibration, and other factors.



Benefits



Merchants will benefit from our Porcelain Disc Insulator in several ways. Here are some of the advantages of using our porcelain insulators.



1. Reliability



Our porcelain insulators are designed to be reliable. They can withstand extreme weather conditions, corrosion, mechanical stresses, and other factors that can cause damage to insulators.



2. Durability



Our porcelain insulators are made of top-quality materials that make them durable and long-lasting. They can withstand different environmental factors and can remain functional for many years.



3. Cost-effective



Our porcelain insulators are cost-effective compared to other materials used for insulators. They provide a long-term solution for electrical industries and can help save costs in the long run.



4. Easy to maintain



Our porcelain insulators are easy to maintain. They require minimal cleaning and can withstand different environmental factors without the need for constant maintenance.



Conclusion



Our Porcelain Disc Insulator is an excellent choice for merchants in electrical industries. It is designed to provide reliable and durable performance under extreme weather conditions. Our porcelain insulators are made of top-quality materials and are suitable for different applications in electrical industries. Merchants can benefit from our porcelain insulators, which are cost-effective, reliable, durable, and easy to maintain. As a manufacturer located in China, we are committed to providing the best quality products and services to our customers. Choose our Porcelain Disc Insulator and enjoy reliable and durable solutions for electrical industries.



Name: Porcelain disc insulator
Type: 11kV Porcelain disc insulator
Related type: ANSI 52-1,52-2,52-3,52-4,52-5,52-6,52-8,52-9,52-10
Voltage Range: 11kV~220kV
Standard: The ANSI standard C29.2 and IEC standard
Graze colors of insulators: Brown or light gray
Mechanical failing load: 45kN,70kN,120kN,160kN and as per client’s request
Material: Alumina and silica porcelain
Application: Overhead lines and transmission lines

Drawing No				11kv 45kn	11kv 70kn	11kv 90kn
Porcelain Dia			mm	255	255	255
Spacing			mm	145	145	145
Total Creepage Distance			mm	320	320	320
Combined Electro Mechanical Strength			kV	45	70	90
Flashover Voltage	Power Frequency	Dry	kV	65	65	65
		Wet	kV	45	45	45
		Positive	kVp	110	110	110
	Impulse	negative	kVp	120	120	120
Withstand Voltage	1 Min. Power Frequency	Dry	kV	50	50	50
	Impulse	Wet	kV	35	35	35
		Positive	kVp	95	95	95
		Negative	kVp	100	100	100
Puncture Voltage			kV	105	105	105
Net Weight approx.			Kg.	4.8	5.0	5.5
Applicable standard: BS137; IEC60383

1. Rich experience in ODM and OEM
2. Excellent One-stop service
3. High Quality Precision Customized forging & Casting services
4. The lowest price
5. Strict quality control
6. We can manufacture it according to customers requirements.

1.Q: Are u the factory or trading company?
A: We are factory who has over 21 years production experiences.

2.Q: What's your main products?
A: porcelain and composite insulators, hardware of all kinds for high-voltage applications and related products.

3. Q: Can I get some samples?
A: Yes, sample order is available for quality check and market test.

4. Q: What’s your payment terms?
A: We usually accept all kinds of payment terms, T/T, L/C, Cash.

5. Q: How can you control your quality?
A: For each production processing, we have complete QC system for the chemical composition, physical and electrical properties. After production, all the goods will be tested according to related standards, and the ex-factory test reports will be sent along with shipment documents.

6. Q: Does your company accept customization?
A:We accept OEM service.

7. Q: What’s your warranty terms?
A: We offer 24 months warranty terms.
